| Model | H60A NBO
The Specifications of H60A Gasoline Pickup |
H60A NBO
H60A NBO Diesel | H60A NBO
H60A NBO Gasoline |
| H60A NBO 2.3T MT Diesel 4WD Standard Cargo Bed | H60A NBO 2.3T AT Diesel 2WD Standard Cargo Bed | H60A NBO 2.3T AT Diesel 4WD Standard Cargo Bed | H60A NBO 2.3T AT Diesel 4WD Flagship Cargo Bed | H60A NBO MT Gasoline 2WD Standard Cargo Bed | H60A NBO MT Gasoline 4WD Standard Cargo Bed | H60A NBO AT Gasoline 2WD Standard Cargo Bed | H60A NBO AT Gasoline 4WD Standard Cargo Bed | H60A NBO AT Gasoline 4WD Flagship Cargo Bed |
Emissions Standard | Euro I~Euro VI | Euro I~Euro VI | Euro I~Euro VI | Euro I~Euro VI | Euro I~Euro VI | Euro I~Euro VI | Euro I~Euro VI | Euro I~Euro VI | Euro I~Euro VI |
| Fuel Type | Diesel | Diesel | Diesel | Diesel | Gasoline | Gasoline | Gasoline | Gasoline | Gasoline |
| Drive Type | 4WD MT | 2WD AT | 4WD AT | 4WD AT | 2WD MT | 4WD MT | 2WD AT | 4WD AT | 4WD AT |
| Trim Level | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Flagship |
| Transmission | 6MT | 8AT | 8AT | 8AT | 6MT | 6MT | 8AT | 8AT | 8AT |
| Vehicle | Vehicle Dimensions (mm) | 5282*1850*1780 | 5282*1850*1780 | 5282*1850*1780 | 5282*1850*1780 | 5282*1850*1780 | 5282*1850*1780 | 5282*1850*1780 | 5282*1850*1780 | 5282*1850*1780 |
| Wheelbase（mm） | 3150 | 3150 | 3150 | 3150 | 3150 | 3150 | 3150 | 3150 | 3150 |
Front/Rear Track(mm) | 1570/1570 | 1570/1570 | 1570/1570 | 1570/1570 | 1570/1570 | 1570/1570 | 1570/1570 | 1570/1570 | 1570/1570 |
| Length × Width × Height(mm) | 1510*1562*475 | 1510*1562*475 | 1510*1562*475 | 1510*1562*475 | 1510*1562*475 | 1510*1562*475 | 1510*1562*475 | 1510*1562*475 | 1510*1562*475 |
| Minimum Turning Radius (m) | 6.4 | 6.4 | 6.4 | 6.4 | 6.4 | 6.4 | 6.4 | 6.4 | 6.4 |
| Minimum Ground Clearance (mm) | 206 | 206 | 206 | 206 | 206 | 206 | 206 | 206 | 206 |
| Curb Weight (kg) | 2005 | 1905 | 2015 | 2015 | 1795 | 1910 | 1810 | 1925 | 1925 |
| Payload Capacity (kg) | 490 | 490 | 490 | 490 | 490 | 490 | 490 | 490 | 490 |
| Approach/Departure Angle(Unloaded) | 33°/25° | 33°/25° | 33°/25° | 33°/25° | 33°/25° | 33°/25° | 33°/25° | 33°/25° | 33°/25° |
| Seating Capacity | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel Tank Capacity (L) | 73 | 73 | 73 | 73 | 73 | 73 | 73 | 73 | 73 |
| Maximum Speed (km/h) | 160 | 160 | 160 | 160 | 160 | 160 | 160 | 160 | 160 |
| NEDC Combined Fuel Consumption (L/100km) | 8.2 | 8.1 | 8.3 | 8.3 | 8.6 | 9.1 | 9.1 | 9.6 | 9.6 |
| Low-Speed 4WD | ● | - | ● | ● | - | ● | - | ● | ● |
| Rear Door Opening Type | Side-Hinged Doors | Side-Hinged Doors | Side-Hinged Doors | Side-Hinged Doors | Side-Hinged Doors | Side-Hinged Doors | Side-Hinged Doors | Side-Hinged Doors | Side-Hinged Doors |
| Engine | Maximum Power (kW) | 122 | 122 | 122 | 122 | 168 | 168 | 168 | 168 | 168 |
| Peak Power Speed (rpm) | 3500 | 3500 | 3500 | 3500 | 5600 | 5600 | 5600 | 5600 | 5600 |
| Maximum Torque (N·m) | 420 | 420 | 420 | 420 | 360 | 360 | 360 | 360 | 360 |
| Peak Torque Speed (rpm) | 1500~2500 | 1500~2500 | 1500~2500 | 1500~2500 | 1400~4000 | 1400~4000 | 1400~4000 | 1400~4000 | 1400~4000 |
| Drivetrain | Brake System | Four-Wheel Disc Brakes | Four-Wheel Disc Brakes | Four-Wheel Disc Brakes | Four-Wheel Disc Brakes | Four-Wheel Disc Brakes | Four-Wheel Disc Brakes | Four-Wheel Disc Brakes | Four-Wheel Disc Brakes | Four-Wheel Disc Brakes |
| Parking Brake | PU | ● | - | - | - | ● | ● | - | - | - |
| Electronic Parking Brake | - | ● | ● | ● | - | - | ● | ● | ● |
| AUTOHOLD | - | ● | ● | ● | - | - | ● | ● | ● |
| Drive Configuration | Part-Time Four-Wheel Drive | Rear-Wheel Drive | Part-Time Four-Wheel Drive | Part-Time Four-Wheel Drive | Rear-Wheel Drive | Part-Time Four-Wheel Drive | Rear-Wheel Drive | Part-Time Four-Wheel Drive | Part-Time Four-Wheel Drive |
| Suspension System | Front Suspension | Double Wishbone with Stabilizer Bar | Double Wishbone with Stabilizer Bar | Double Wishbone with Stabilizer Bar | Double Wishbone with Stabilizer Bar | Double Wishbone with Stabilizer Bar | Double Wishbone with Stabilizer Bar | Double Wishbone with Stabilizer Bar | Double Wishbone with Stabilizer Bar | Double Wishbone with Stabilizer Bar |
| Leaf Springs | ● | - | - | - | ● | ● | - | - | - |
| Five-Link | - | ● | ● | ● | - | - | ● | ● | ● |
| Tires | 255/60R18
Aluminum Wheels | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Spare Tire | 255/60R18
Steel Wheel | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Comfort Features | Steering Wheel Material | Leatherette | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Steering Wheel Height | Manual Height Adjustment | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Multifunction Steering Wheel | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Steering System | Electric Power Steering | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Climate Control | Dual-Zone Automatic Climate Control | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rear Air Vents | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| PM2.5 Cabin Air Filter | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Seat Material | PVC | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Driver Seat Adjustment | 6-Way Manual Adjustment | ● | ● | ● | - | ● | ● | ● | ● | - |
| 8-Way Power Adjustment | - | - | - | ● | - | - | - | - | ● |
| Seat Cushion and Backrest Ventilation (3 Levels) and Heating (3 Levels) | - | - | - | ● | - | - | - | - | ● |
| Front Passenger Seat Adjustment | 4-Way Manual Adjustment | ● | ● | ● | - | ● | ● | ● | ● | - |
| 4-Way Power Adjustment | - | - | - | ● | - | - | - | - | ● |
| Seat Cushion and Backrest Ventilation (3 Levels) and Heating (3 Levels) | - | - | - | ● | - | - | - | - | ● |
| Second-Row Headrest Type | Two Independent, Height-Adjustable | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rear Seats | Fixed | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Instrument Cluster | Speedometer Tachometer TFT Color Display | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Smart Key with Push-Button Start | Keyless Entry (Driver and Front Passenger) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Front Door Glass | Green-Tinted Glass | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rear Door Glass | Green-Tinted Glass | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Windshield | Green-Tinted Glass with UV and Heat Protection | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rear Windshield | Green-Tinted Glass | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rear Window Defroster | - | - | - | ● | - | - | - | - | ● |
| Power Windows | Driver: One-Touch Up/Down + Anti-Pinch + Power
Front Passenger: Power | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Second Row : Power | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rain-Sensing Windshield Wipers | High/low speed with adjustable automatic intermittent | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Hood | Thai-specification styling | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Automatic Headlights | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Exterior Mirrors | Chrome finish + manual folding + power adjustment + turn signal indicators | ● | ● | ● | - | ● | ● | ● | ● | - |
| Chrome finish + power folding + power adjustment + turn signal indicators + camera | - | - | - | ● | - | - | - | - | ● |
| Heated Exterior Mirrors | - | - | - | ● | - | - | - | - | ● |
| Interior Rearview Mirror | Manual anti-glare | ● | ● | ● | - | ● | ● | ● | ● | - |
| Auto-dimming | - | - | - | ● | - | - | - | - | ● |
| Sun Visors | Driver: Sun visor (PVC) | ● | ● | ● | - | ● | ● | ● | ● | - |
| Driver: Sun visor with illuminated vanity mirror and ticket holder | - | - | - | ● | - | - | - | - | ● |
| Front Passenger: Sun visor (PVC) | ● | ● | ● | - | ● | ● | ● | ● | - |
| Front Passenger: Sun visor with illuminated vanity mirror (PVC) | - | - | - | ● | - | - | - | - | ● |
| Eyeglasses holder | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Glove compartment (unlocked) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Interior Assist Handles | One for front passenger + one each for second row left/right (roof-mounted) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Boarding Assist Handle | One front passenger (A-pillar) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Cup Holders | Two in center console | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| USB | Two (lower center console + center armrest storage) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| TYPE-C | Two (lower center console + center armrest storage) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| 12V Power Outlet | Two (lower center console + center armrest storage) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Exterior | Roof Rails | Longitudinal roof rails | - | - | - | ● | - | - | - | - | ● |
| Side Steps | Fixed | ● | o | ● | ● | o | ● | o | ● | ● |
| Antenna | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Electromagnetic fuel filler door | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Front Tow Hook | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rear Spoiler | - | - | - | ● | - | - | - | - | ● |
| Front Air Dam/Spoiler | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Interior Door Handles | Chrome finish | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Exterior Door Handles / Tailgate Handle | Chrome finish | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Front Bumper | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rear Bumper | Body-colored | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Off-road rear bumper for P15MC variant (bundled with rear recovery device, optional; dealer-installed) | - | - | o | o | - | - | - | o | o |
| Front Grille | Chrome finish | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Fender Flares | Front and rear | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Tailgate mechanical lock | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Cargo bed liner / Bed protector | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Safety Features | Driver and front passenger airbags | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Front side airbags | - | - | - | ● | - | - | - | - | ● |
| Side curtain airbags | - | - | - | ● | - | - | - | - | ● |
| ESC | ABS (Anti-lock Braking System) + EBD (Electronic Brakeforce Distribution) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| HBA (Hydraulic Brake Assist) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| HHC (Hill Hold Control) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| HDC (Hill Descent Control) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| VDC (Vehicle Dynamic Control) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| TCS (Traction Control System) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Hazard/Emergency Brake warning | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| RMI (Rollover Mitigation) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Cruise Control | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Transfer Case | Center Differential Lock | ● | - | ● | ● | - | ● | - | ● | ● |
| Electronically controlled differential lock | Front axle | - | - | - | o | - | - | - | - | o |
| Electronically controlled differential lock | Rear axle | - | - | - | o | - | - | - | - | o |
| Tire Pressure Monitoring System (TPMS) | - | - | - | ● | - | - | - | - | ● |
| Engine Immobilizer | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| High-Mounted Stop Lamp (HMSL) | Deleted when roll bar is equipped | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rearview Camera | Displayed on 10.25-inch screen | ● | ● | ● | - | ● | ● | ● | ● | - |
| Rear Parking Sensors | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| 540° Camera System | 10.25-inch screen, HD with transparent chassis and transparent hood views | - | - | - | ● | - | - | - | - | ● |
| Level 2 ADAS Forward Assistance | ACC+AEB+LKA+TJA/ICA+LDW+IHBC+ELK+TSR/ISLI
optional for C-NCAP 3-star rating | - | - | - | o | - | - | - | - | o |
| Central Door Locking | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Radiator Under Guard | Resin | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Engine Under Guard | Resin | ● | - | ● | ● | - | ● | - | ● | ● |
| Headlights | LED | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Manual Height Adjustment | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Front Fog Lights | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rear Fog Light | Rear Combination Lamps | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Tail Lamps | LED | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Daytime Running Lights (DRL) | LED, activated with headlights | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Driver Seat Belt | Three-point with load limiter and height adjustment | ● | ● | ● | - | ● | ● | ● | ● | - |
| Three-point with pretensioner, load limiter, and height adjustment | - | - | - | ● | - | - | - | - | ● |
| Front Passenger Seat Belt | Three-point with load limiter and height adjustment | ● | ● | ● | - | ● | ● | ● | ● | - |
| Three-point with pretensioner, load limiter, and height adjustment | - | - | - | ● | - | - | - | - | ● |
| Second rowSeatBelts | Three-point | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Child Safety Locks | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Audio-Visual System | 10.25-inch Display Screen (Rear View Camera | ● | ● | ● | - | ● | ● | ● | ● | - |
| 10.25-inch Display Screen 360° Surround View Camera | - | - | - | ● | - | - | - | - | ● |
| Connected Vehicle | Climate Control / Remote Control | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| In-Vehicle Apps | Music, Navigation, Voice Recognition | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Mobile App | Baidu Maps | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Shared Audio | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Smartphone Integration | iOS + Android (Yilian Connectivity) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Speakers | 4 Speakers | ● | ● | ● | - | ● | ● | ● | ● | - |
| 6 Speakers | - | - | - | ● | - | - | - | - | ● |
| Other Features | FOTA | ESC、EPS、ADAS、DA、T-BOX、CCM
Driver Assistance Controller | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Tools | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Roll Bar (Dealer-Installed), Special Vehicle Development | o | o | o | o | o | o | o | o | o |
| Reflective Safety Vest | ● | ● | ● | ● | ● | ● | ● | ● | ● |
| Rear Tow Hitch | Rear Tow Hitch + Electrical Connector (Special Vehicle Development, Dealer-Installed) | - | - | o | o | - | - | - | o | o |
| Legend: ● Standard Equipment − Not Available ○ Optional Specifications are subject to change without notice. ZZDFIE reserves the right of final interpretation. |
